Special Order

Trimble Adapter, SS, Monument, 1 1/2" Pipe.

The Claw™ Series is designed to prevent the user from over tightening the pole clamp screw and accidentally crushing or cracking the pole The clamping function is limited so over-tightening cannot occur Made of durable anodized aluminum for years of trouble-free use in the field These clamps are compatible with our existing Quick-Release cradles for most popular data controllers or you can pair it with the Claw Quick-Release Cradle for your collector/controller Quick-Release cradles plug directly into Quick-Release Pole Clamps Designed to fit a pole diameter of 1.25 in (32 mm), however a 1 inch (25.4 mm) pole can be used Features a 40-minute vial built on to the clamp The Delrin Adapter can be purchased seperately to increase the OD of a 1-inch pole to 1.25-inches (#D11145) Weighs 0.38 lb (0.17 kg)

The original Open Clamp Pole Bracket and Cradle technology designed by SECO These products offer a fast and efficient way to mount data collectors or controllers to antenna poles and rover rods The aluminum open clamp design features a quick-release button and a stainless steel clamp screw that attaches to the pole Depressing the quick-release button will allow the Claw Quick-Release Cradle or standard cradle to rotate in to a comfortable position for reading the data collector or controller Manufactured from black anodized aluminum Designed for standard 1.25 inch OD rods and poles Includes Quick Release and Battery Slot Weighs 0.46 lb (0.21 kg)

Seco Monster Gear Bag has four deep-zippered pockets – two front and two side Two interior pockets – 14 x 12 x 2 inches (35.56 x 30.48 x 5.08 cm) with hook-and-loop closures Heavy-duty nylon webbing carrying straps Enough space to carry all of your tools, clothes, or other miscellaneous gear Dimensions: 30 x 14 x 20 inches (76.2 x 35.56 x 50.8 cm) Orange Weighs 3.78 lb (1.72 kg)

Incorporates a simple stainless steel locking mechanism that’s easy to set while adjusting the prism and target tilt The heavy-duty 62 mm silver-coated prism is sealed in a strong canister with an ‘O’ ring to prevent water and dust from getting inside The prism can be mounted in either 0 or -30 mm offset positions Tilting axis height is 115 mm 5.5 x 7-inch Target size Target Color is Flo Orange with Black Weighs 1.59 lb (0.72 kg)

Lightweight aluminum scanner sphere 230 mm diameter, accuracy < 2 mm Painted non-glare white Female 5/8 x 11 threaded mounting Center height is 114 mm from bottom flat Weighs 2.70 lb (1.22 kg)

This 25 mm, copper-coated prism features aluminum double yoke construction w/tilting coaxial target Two on-board 130-minute vials — top and bottom Includes replaceable plumb bob point 0 and -30 mm Offset Flo Yellow Weighs 0.62 lb (0.28 kg)

The -30/0 mm offsets enable the Premier Prism Assembly to be used with Nikon, Topcon, Sokkia and other total stations The 62 mm copper-coated prism is encased in a heavy-duty canister with M20 threads Features a prism accuracy of <5 seconds Tilting holder is constructed of anodized aluminum Height of the prism in the holder is 100 mm and -30/0 mm offsets The mounting base features standard female 5/8 x 11 threads Target size 6 x 9 inches (15.2 x 22.8 cm) Target Colors are Flo Orange with Black Weighs 1.75 lb (0.80 kg)

These aluminum leveling rods are made of a light and durable alloy The telescopic sections are anodized and silk-screened with moisture-resistant ink Each rod section uses sturdy polycarbonate buttons that lock each section when extended; the height gauge is on the back side These rods are 3-Sections and come in 10ths graduations Length 9 ft Each rod includes a special level and protective bag Weighs 2.40 lb (1.10 kg)

TDC600 Dual battery, BA7800 3.8V 8000mAh, Gang Charger with AC Adapter This external dual battery & gang charging accessory assists users who may have longer workday needs or to help with campaigns where teams are deployed with the same shared TDC600 hardware and cannot afford downtime. A dual charger can also help quickly charge large stocks of batteries that have been safely stored.

Bright 650-nm focused laser dot Circular vial w/ 8-minute sensitivity Standard three-prong forced centering with center lines Included is a standard 3 volt CR2 lithium battery Weighs 1.65 lb (0.75 kg)

SECO Pole Clamp locks securely to the pole, no slipping! Tilting Feature with three positions, +10, +30 or +50 degrees. Quick Release from Pole Clamp for taking photos, etc. and also allows landscape or portait orientation of the display.

Laserline Carrying / Storage Bag features sturdy black cordova nylon with strap, velcro flap and pocket for bracket and detector. 15-foot (5-meter).

Anodized aluminum body Male and female 5/8 x 11 threads Height is 21 mm Center height is 135 mm with 230 mm Sphere (6704-001) Weighs 0.05 lb (0.02 kg)

Extends to 4.80 ft (1.5 m) and collapses to 2.26 ft (0.7 m) Dual graduations: tenths and mm increments Constructed of sturdy aluminum Quick-Release Lock and 40 minute vial Weighs 2.33 lb (1.80 kg)

The 62 mm Premier Prism Assembly features a copper-coated canister type prism. It is waterproof, and has a M20 universal mounting thread.The tilting holder is anodized aluminum and features an improved locking clamp screw design and an 18-gauge steel target. Target Color is Yellow with Black.

The ML-1 is a high quality magnetic locator with solid tube through construction that provides stability and strength. Whether you're seeking corner markers (iron or steel), well casings, steel drums or septic tank handles, this is the go-to magnetic locator for you. The ML series offers simple one-handed operation with an easy-to-learn keypad featuring only three buttons - no menus or cumbersome instructions to follow. The audio unit has the volume built into the on/off key; just hold down the key while it cycles through the settings. The ML-1 features strong monotube construction, providing structural integrity you can count on.
