Tribrachs & Adapters

These tripods accommodate 5/8 x 11 instruments and are designed for all types of jobs The telescopic Aluminum (Round) legs allow for setup Extends to 65 in (1.65 m) Features a Quick Clamp lock type with a Triangle/Flat head Tripod Hardware comes in Orange Weighs 9.35 lb (4.25 kg)

SECO 5/8 X 11 Prism Mounting Adapter Kit. 1/4 x 20 Male to 5/8 x 11 Male Mounting Adapter.

Features 5/8-11 Female to 1/4-20 Female Weighs 0.20 lb (0.09 kg)

Quick Change Adapter . Use the Pole Adapter on a SECO Quick Change™ Poles to achieve a target height of 150 mm.

This adapter adds 76.22 mm to the pole length. Use with #5187-00 GPS Quick-Release Adapter.

TDC600 Range pole adapter / bracket. Range pole bracket provides the ability for users to operate in landscape or portrait modes to improve workflows that require forms/data to be entered. Ideal when using the TDC600 with an external receiver like the Catalyst DA1 or R2 receiver for a convenient all-on-the-pole solution.

Monopole bracket for Geo 7 series handhelds, with quick-release tilt mechanism. This accessory can be used with the following products: Trimble Geo 7 series handhelds  Trimble GeoExplorer 6000 series handhelds

Tilting pivot allows measurement on sloped or flat pipe surfaces Standard topo shoe length, 3.375-inch (85.7-mm), compatible with all SECO Poles 2-inch (50.8-mm) diameter chrome-plated steel housing with grade-8 ceramic magnet ring Magnet has 40 pounds of pull force on 3/8-inch (9.5-mm) clean steel plate Black anodized machined 6061 aluminum body Machined brass pole connecter with female 5/8 x 11 threads Weighs 0.55 lb (0.25 kg)

Use the Pole Adapter on a SECO Quick Change™ Poles to achieve a target height of 150 mm For: GPS Antenna Target Height: 0 mm Length: 150 mm Weighs 0.22 lb (0.10 kg)

The Claw™ Series is designed to prevent the user from over tightening the pole clamp screw and accidentally crushing or cracking the pole The clamping function is limited so over-tightening cannot occur Made of durable anodized aluminum for years of trouble-free use in the field These clamps are compatible with our existing Quick-Release cradles for most popular data controllers or you can pair it with the Claw Quick-Release Cradle for your collector/controller Quick-Release cradles plug directly into Quick-Release Pole Clamps Designed to fit a pole diameter of 1.25 in (32 mm), however a 1 inch (25.4 mm) pole can be used Features a 40-minute vial built on to the clamp The Delrin Adapter can be purchased seperately to increase the OD of a 1-inch pole to 1.25-inches (#D11145) Weighs 0.38 lb (0.17 kg)

The original Open Clamp Pole Bracket and Cradle technology designed by SECO These products offer a fast and efficient way to mount data collectors or controllers to antenna poles and rover rods The aluminum open clamp design features a quick-release button and a stainless steel clamp screw that attaches to the pole Depressing the quick-release button will allow the Claw Quick-Release Cradle or standard cradle to rotate in to a comfortable position for reading the data collector or controller Manufactured from black anodized aluminum Designed for standard 1.25 inch OD rods and poles Includes Quick Release and Battery Slot Weighs 0.46 lb (0.21 kg)

Adapt the thread size to 5/8 x 11 for mounting prisms on the leveling rod’s female adapter Weighs 0.20 lb (0.09 kg)

This assembly is for 1.50-inch diameter poles Features the 40-minute vial (#D11232) Includes screws Weighs 0.19 lb (0.09 kg)

Laserline Mfg. Inc. is the world's largest manufacturer of direct reading (Lenker style) grade rods, which feature a movable tape face allowing you to set the actual benchmark elevation, or any elevation, above or below the bench into the rod. Laserline detector brackets attach to the special rail slide on laser grade rods. Made of rugged, lightweight extruded aluminum with a black anodized finish.

Trimble Adapter, SS, Monument, 1 1/2" Pipe.

Male and female 5/8 x 11 threads Physical height is 117 mm Center height is 265 mm with 230 mm Sphere (6704-001) and Tribrach Adapter (2070-00) Weighs 0.36 lb (0.16 kg)

The original Open Clamp Pole Bracket and Cradle technology designed by SECO These products offer a fast and efficient way to mount data collectors or controllers to antenna poles and rover rods The aluminum open clamp design features a quick-release button and a stainless steel clamp screw that attaches to the pole Depressing the quick-release button will allow the Claw Quick-Release Cradle or standard cradle to rotate in to a comfortable position for reading the data collector or controller Manufactured from black anodized aluminum Designed for standard poles or rods with a 0.75 to 1.25 inch OD Includes Compass and 40-Minute Vial Weighs 0.60 lb (0.27 kg)

This 5/8 x 11 stainless steel adapter adds 23.8 mm to length of rod Weighs 0.06 lb (0.03 kg)

Bright 650-nm focused laser dot Circular vial w/ 8-minute sensitivity Standard three-prong forced centering with center lines Included is a standard 3 volt CR2 lithium battery Weighs 1.65 lb (0.75 kg)
