BX992 Marine Dual Frequency Receiver

The Trimble BX992 supports triple frequency for the GPS, GLONASS, BeiDou and Galileo constellations. As the number of satellites in the constellations grows the BX992 is ready to take advantage of the additional signals. This delivers the quickest and most reliable RTK initializations for centimeter positioning. For applications that do not require centimeter accuracy the BX992 integrated GNSS-inertial engine also delivers high accuracy GNSS, DGNSS positions in the most challenging environments such as urban canyons. With the latest Trimble Maxwell™ 7 technology, the BX992 provides: • 2 x 336 Tracking Channels • Trimble EVEREST™ Plus multipath mitigation • Advanced RF Spectrum monitoring and analysis • Proven low-elevation tracking technology With the option of utilizing Trimble OmniSTAR® or Trimble RTX® correction service, the BX992 delivers varying

Compact, dual-antenna receiver enclosure with integrated inertial navigation for continuous centimeter accuracy.

The BX992 is a dual-antenna receiver enclosure with an integrated inertial navigation system powered by the BD992-INS.

Specifications

• Robust high accuracy positions and orientations are produced in all environments due to the integration of inertial sensors on the same module
• Delivers 336 tracking channels, Trimble Everest Plus^™ multipath mitigation, advanced RF spectrum monitoring/ analysis and proven low-elevation tracking technology
• Offers continuous positioning in GNSS denied areas while delivering high-update rate position and orientation solutions
• Flexible RS232, USB and ethernet interfacing
