Accessories

SECO Tribrach / GPS Tripod Removable Plug Adapter - Brass Center.

The open clamp attachment allows quick and easy connection to the pole. Will connect to 19- and 32-mm diameter poles. The brass male 5/8 x 11 captive stud is easily removed for direct attachment of the radio antenna to the bar.

This adapter has male 5/8 x 11 threads to Quick-Release Weighs 0.08 lb (0.04 kg)

This 5/8 x 11 stainless steel adapter adds 23.8 mm to length of rod Weighs 0.06 lb (0.03 kg)

Female 5/8 x 11 with quick release tip. Adds 23.8 mm to length of rod.

The Eclipse™ prism assembly features a water-resistant, nitrogen charged, 62 mm prism canister and reversible target Can be set at a -40 mm, which offers optimal angle measurements, even when tilting in either the horizontal or the vertical axis A -30 mm adapter is included Height to center of glass: 0.38 ft (115 mm) Weighs 1.15 lb (0.52 kg)

SECO Double Socket Arm, 1 ", Ball + Socket. Use the Ball-and-Socket Link for your custom solution  Fits the 1-inch ram ball on cradles and clamps  Weighs 0.27 lb (0.12 kg)

This prism allows for easy determination of right angle points or perpendicular points between two targets.

These tripods accommodate 5/8 x 11 instruments and are designed for all types of jobs. The telescopic Aluminum (Round) legs allow for setup to extend to 65 in (1.60 m). Features a quick clamp and a triangle/flat head tripod. Weighs 7.45 lb (3.38 kg).

Anodized aluminum plate The three bottom anchor bolts are embedded in concrete during installation With 5/8 x 11 threaded stud for Tribrach adapter centered on the plate Weighs 2.29 lb (1.04 kg)

The Claw™ Series is designed to prevent the user from over tightening the pole clamp screw and accidentally crushing or cracking the pole The clamping function is limited so over-tightening cannot occur Made of durable anodized aluminum for years of trouble-free use in the field These clamps are compatible with our existing Quick-Release cradles for most popular data controllers or you can pair it with the Claw Quick-Release Cradle for your collector/controller Designed to fit a pole diameter of 1.25 in (32 mm), however a 1 inch (25.4 mm) pole can be used Features a 40-minute Vial and Compass built on to the clamp The Delrin Adapter can be purchased separately to increase the OD of a 1-inch pole to 1.25-inches (#D11145) Weighs 0.43 lb (0.19 kg)

The Claw™ Series is designed to prevent the user from over tightening the pole clamp screw and accidentally crushing or cracking the pole The clamping function is limited so over-tightening cannot occur Made of durable anodized aluminum for years of trouble-free use in the field These clamps are compatible with our existing Quick-Release cradles for most popular data controllers or you can pair it with the Claw Quick-Release Cradle for your collector/controller Quick-Release cradles plug directly into Quick-Release Pole Clamps Designed to fit a pole diameter of 1.25 in (32 mm), however a 1 inch (25.4 mm) pole can be used Features a 40-minute vial built on to the clamp The Delrin Adapter can be purchased seperately to increase the OD of a 1-inch pole to 1.25-inches (#D11145) Weighs 0.38 lb (0.17 kg)

Made of durable anodized aluminum for years of trouble-free use in the field. These clamps are compatible with our existing Quick-Release cradles for most popular data controllers or you can pair it with the Claw Quick-Release Cradle for your collector/controller.

Seco Claw™ Cradle is a new and improved clamping system featuring an innovative clamping device that keeps your expensive data collecting hardware snug on the pole where it belongs without crushing it.

These Claw™ clamps are also made of durable anodized aluminum The Claw technology allows maximum tightening on the pole without crushing The Ball-and-Socket versions allow a handheld data collector to be in more positions Customize your own solution with these components The clamps are designed to fit a pole diameter of 1.25 inch (32 mm) Ball-and-Socket Cradle (1-inch ram ball, designed for 1.25 inch OD poles) Plain with 1 inch Ball Weighs 0.31 lb (0.14 kg)

Center Punch Point fits all poles or products with male 5/8 x 11 threads. Hardened steel point will mark all metal and non-metal surfaces. Weighs 0.20 lb (0.09 kg)

This tool checks and adjusts optical plummet tribrachs & tribrach bubbles. The adjuster is constructed of precision-machined anodized aluminum with a 2-minute bubble.

The original Open Clamp Pole Bracket and Cradle technology designed by SECO These products offer a fast and efficient way to mount data collectors or controllers to antenna poles and rover rods The aluminum open clamp design features a quick-release button and a stainless steel clamp screw that attaches to the pole Depressing the quick-release button will allow the Claw Quick-Release Cradle or standard cradle to rotate in to a comfortable position for reading the data collector or controller Manufactured from black anodized aluminum Designed for standard poles or rods with a 0.75 to 1.25 inch OD Includes Compass and 40-Minute Vial Weighs 0.60 lb (0.27 kg)

3.37 inch (85.6 mm) aluminum body Removable point Weighs 0.10 lb (0.05 kg)

For 2-inch pipe with MPT 2 x 11-1/2 TPI The adapter has 3.20-inch (8.19 cm) diameters and overall heights of 3.036 inches (7.71 cm) Includes a removable brass 5/8 x 11 male stud that is adjustable in azimuth and held in location by two set screws The adapters are leveled by three screws with a tilt range +/- 7° The height above the pivot point to the stud shoulder is 1.37 inches (3.50 cm) The height below the brass 5/8 stud to the shoulder is 0.463 inches (1.18 cm) The axis height is engraved on the outside of the monuments Weighs 6.80 lb (3.08 kg)
