The Eclipse™ prism assembly features a water-resistant, nitrogen charged, 62 mm prism canister and reversible target Can be set at a -40 mm, which offers optimal angle measurements, even when tilting in either the horizontal or the vertical axis A -30 mm adapter is included Height to center of glass: 0.38 ft (115 mm) Weighs 1.15 lb (0.52 kg)

Construction grade leveling (CR) rods offer a rectangular shape with rounded back corners for better gripping Scale width graduated to fill the entire face of the rod, Measuring scale on the back side that allows for overall height readings Special molded stand-off ribs protect the scales from wear Made with strong fiberglass, which is waterproof and corrosion-resistant CR Rod series is non-conductive Perfect for laser detector mounting with no special brackets required Three section rod Collapsed length is 58.375 inches (1.48 m) Graduations in 10ths Length 13 ft Weighs 5.00 lb (2.26 kg)

Flat shiner is 2-1/4 in (57 mm) in diameter and punched in the center with crimped edges. Shiners are used for indicating semi-permanent points with spikes or nails. Comes in a box of 250.

The Gardner Rod rest is a self-retracting ‘kickstand’ for survey rods Attaches quickly with one thumbscrew and is activated by simply pushing down a few inches on the handle Legs self-retract when the rod is lifted Made of durable anodized aluminum that won’t rust or fatigue and has a stainless steel clamp screw Holds the rod at a 20-degree zenith angle 1.25 inch Outside Diameter Weighs 1.55 lb (0.70 kg) Pole not included

This adapter adds 76.22 mm to the pole length. Use with #5187-00 GPS Quick-Release Adapter.

Female 5/8 x 11 with quick release tip. Adds 23.8 mm to length of rod.

This 5/8 x 11 stainless steel adapter adds 23.8 mm to length of rod Weighs 0.06 lb (0.03 kg)

This adapter has male 5/8 x 11 threads to Quick-Release Weighs 0.08 lb (0.04 kg)

The open clamp attachment allows quick and easy connection to the pole. Will connect to 19- and 32-mm diameter poles. The brass male 5/8 x 11 captive stud is easily removed for direct attachment of the radio antenna to the bar.

SECO Tribrach / GPS Tripod Removable Plug Adapter - Brass Center.

The Seco GPS Tripod bag features a full-length zipper and shoulder strap. Designed to carry the tripod without the point on the center pole to prevent damage to the pole.

Height of 120 mm (0.394 ft) 40-min vial Removable tip Weighs 0.40 lb (0.18 kg)

The bag holds 48inch lath and features a sturdy, adjustable shoulder strap and hand loop to carry the load.

SECO’s Heavy-Duty Column Clamp has a solid stable design and works with all 5/8 x 11 instruments The adjustable column rotates and moves vertically to orient the instrument when needed and features 12-inches (30.48 cm) of height adjustment Includes a 2-inch (5.08 cm) by 10 ft (3.05 m) strap rated for a 2200 pound load and a heavy duty ratchet to create a strong connection to both round and square columns The centerline of the 5/8 x 11 stud to column measures 15 inches (38.1 cm) Constructed of structural aluminum for industrial applications and stainless steel hardware Weighs 13.75 lb (6.24 kg)

These tripods accommodate 5/8 x 11 instruments and are designed for all types of jobs Features a built-in circular vial in the instrument head and safety chains on the legs to prevent slipping on hard surfaces The telescopic Aluminum (Round) legs allow for setup to extend 91.2 in (2.32 m) Featuring a Quick Clamp lock and an Elevator/Round head Collapses to 4.26 ft (1.26m) Will fit in tripod carrying bag 8154-12 Black Hardware Weighs 16.30 lb (7.39 kg)

Carries up to 50 lath or rebar 1000 denier Cordura® bag has a thick, reinforced bottom of leather and the Rhinotek™ abrasive-resistant materials The exterior features a hammer loop, paint can holder, marker pen slots, and a pocket for miscellaneous gear Dimensions: 9 x 38 inches (2.54 x 96.52 cm) Weighs 0.22 lb (0.10 kg)

5/8 X 11 aluminum prism height adapters allow the base pole to be used with other manufacturer’s 360° Prisms Converts a robotics pole to a GPS pole Weighs 0.26 lb (0.12 kg)

The jumbo triple prism bag is designed to carry one triple prism assembly with targets or tribrachs. It measures 9 x 9 x 5 in (23 x 18 x 6 cm).

Level Vial assembly fits most 8ft & 12ft Prism Rods Assembly is for 1.25-inch diameter poles Featuring a 40-minute vial (#D11242) Top Adjusted Vial Holder Assembly Includes screws Weighs 0.14 lb (0.06 kg)
